Dynamix -40km 10/100
Fiber Optic Media Converter 10/100M, single mode 1310 nm, 40 km
Specification | Front panel | Application | Ordering information

View Larger Picture

 Dynamix -40km 10/100 fiber optic media converter be used Ethernet's electric signal to transmit photo signal’s photo electricity signal transceiver, the feature is adopt one fiber cable can receive and transmit photo signal in-phase, enhance one double transmit energy than existing optical fiber, economized fiber cable's source.

Dynamix -40km 10/100 is a self-adapted single-fiber dual-direction fiber optic media converter with 10/100M.
Dynamix -40km 10/100 10/100BAse-Tx to 100 Base-Fx Fast Ethernet media converter is fully compliant with all IEEE802.3u standards.

Dynamix -40km 10/100 singlemode media converter has one RJ-45 interface and one SC single-fiber interface, separate for use to connecting twisted-pair and fiber.
Dynamix -40km 10/100 media converter have LED indicator.

 User's manual

Quick start
         0.05 Mb
• Optical port working mode is 100M Full Duplex, LAN port is Auto Negotiation
• Support electricity port's 10M 100M mode or self-adapt mode's switch
• Electricity port support auto-negotiation function, auto-regulation transmit mode and transmit speed
• Connect type: SC
• Fiber type: singlemode
• Built-in power supply
• Wavelength: 1310 nm
• Typical distance: 40KM
• Min TX PWR: -10.0dBm
• Max TX PWR:-3.0dbm
• Sensitivity:<-33dbm
• Link budget:23.0dbm
• Support storage transmit mode
• Prot supply Auto-MDI/MDIX automatic reverse
Back to Top

Standards
 Accord with IEEE802.3 IEEE802.3u IEEE802.3x IEEE802.1q 100Base-T,100Base-TX, 100Base-FX standard

Protocol
 Support TCP/IP PPPOE DHCP ICMP NAT protocol

Interface
 electric port RJ-45
fiber port: SC

Flow control mode
 full duplex adopt IEEE802.3X,
 half duplex adopt Backpressure’s standard

Electricity port
 support auto-negotiation function, auto-regulation transmit mode and transmit speed

Twisted-pair
 CAT.5 UTP cable

Singlemode fiber
 8/125,8.3/125, 9/125µm

LED indicator
 POWER,
TX100,
FX100,
FX Link/ACT,
TX Link/ACT,
FDX

Working temperature
 0~50 °C

Storage temperature
 -20~70 °C

Humidity
 5%~90%(non-condensing)

Size
 26*70*94mm(H*W*L)

Back to Top


Back to Top


Back to Top
Dynamix -40km 10/100  Fiber Optic Media Converter 10/100M, single mode 1310 nm, 40 km
